Resolution: 4mp

Day/Night Switch

Built-in microphone and built-in speaker for two-way audio and audio alarm

Detection angle: Horizontal: 80°/ vertical: 30°

Detection range: Up to 12 m

Movement range (Pan): 0° to 340°

Movement range (Tilt): 0° to 80°

Support manual adjustment of the radar angle: 0°, 10°, and 20°

Simultaneous live view: Up to 6 channels

User / host: Up to 32 users

SIM type: Nano SIM

Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Battery type: Ternary lithium

Battery capacity: 50.76 Wh

Battery cycle: 27 hours (1.85 W) - Full charge battery runtime without solar input

Battery life: More than 800 cycles

Typical power scenarios: 1.85 W (4G working)

Standby scenarios: 80 mW

Max. Power consumption: 7 W

Power Supply: 12 VDC ± 25%

*For debugging only

10 W (deviation: ± 5%) Solar panels

Power Interface:

Power supply interface: four-core aviation connector

Extended solar panel: four-core aviation connector

Protection: IP66

Notes: MicroSD Card not included

Reference: DS-2DE2C400IWG-K/4G/C05S10
